Egis MIDI / AMI Fuse Blocks
Egis MIDI / AMI fuse blocks protect 30-200 A feeds with bolt-down MIDI fuses. Choose single blocks with black or sealed covers, or 3x and 5x ganged blocks with sealed covers and M8 inputs for clean multi-circuit distribution.
Key Features & Upfitter Specs
- Options On This Page: 3806/3808 3x blocks and 3906/3908 5x blocks (M6 or M8 outputs), 3810B and 3901B single blocks, 3810-03B 3-gang fuse set and the 3914B compact MAXI replacement block.
- Ratings: 30-200 A MIDI / AMI fuses; sealed covers on 39xx and 3806/3808 series.
- Hardware: Stainless steel self-locking M5/M6/M8 hardware; high temperature glass-filled nylon.
- Pair With: Egis MIDI distribution blocks and open block busbars for expandable layouts.
- Warranty: 4-year Egis warranty.
Specifications
| Configuration | 3x Fuse Block with Sealed Cover, M8 Input, M6 Outputs - Retail Pack, 3x Fuse Block with Sealed Cover, M8 Input, M6 Outputs, 3x Fuse Block with Sealed Cover, M8 Inputs/Outputs - Retail Pack, 3x Fuse Block with Sealed Cover, M8 Inputs/Outputs, Fuse Set - 3 Gang, MIDI Fuse Block, M5 Stainless Hardware, Black Cover, AMI / MIDI Fuse Block, 30-200 A, Sealed, 5x Fuse Block with Sealed Cover, M8 Inputs, M6 Outputs, 5x Fuse Block with Sealed Cover, M8 Inputs/Outputs, Compact Medium Amp AMI/MIDI Fuse Block (MAXI Replacement) |
| Manufacturer | Egis |
| Tags | |
|---|---|
| Tags |
|
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Part Numbers & Pricing 10 part numbers
Approved resellers see discounted pricing in this table after signing in.
Apply for a reseller account
Sign in
| Part Number | Manufacturer | Configuration | Price | Select |
|---|---|---|---|---|
3806
|
Egis | 3x Fuse Block with Sealed Cover, M8 Input, M6 Outputs - Retail Pack | $ 47.99 | |
3806B
|
Egis | 3x Fuse Block with Sealed Cover, M8 Input, M6 Outputs | $ 46.99 | |
3808
|
Egis | 3x Fuse Block with Sealed Cover, M8 Inputs/Outputs - Retail Pack | $ 48.99 | |
3808B
|
Egis | 3x Fuse Block with Sealed Cover, M8 Inputs/Outputs | $ 47.99 | |
3810-03B
|
Egis | Fuse Set - 3 Gang | $ 23.99 | |
3810B
|
Egis | MIDI Fuse Block, M5 Stainless Hardware, Black Cover | $ 8.99 | |
3901B
|
Egis | AMI / MIDI Fuse Block, 30-200 A, Sealed | $ 23.99 | |
3906B
|
Egis | 5x Fuse Block with Sealed Cover, M8 Inputs, M6 Outputs | $ 55.99 | |
3908B
|
Egis | 5x Fuse Block with Sealed Cover, M8 Inputs/Outputs | $ 55.99 | |
3914B
|
Egis | Compact Medium Amp AMI/MIDI Fuse Block (MAXI Replacement) | $ 18.99 |
No part numbers match your filter.
Prices are per unit on your current pricelist, excluding tax and shipping. Select a row to add that part number to your cart.
